Product Details
|
Technical Data Sheet |
||||
|
Frequency Range |
0.5~18GHz |
Finish |
Painted Blue_ RAL #5007 |
|
|
Insertion Loss |
≤12.0dB (Above 12.04dB Split) |
Connector Body |
Passivated Stainless Steel |
|
|
VSWR |
Input ≤2.00:1 Output ≤1.80:1 |
Housing |
Aluminum, 6061 T6 Clear Chem Conversion Film |
|
|
Isolation |
≥14dB @0.5-0.6GHz ≥16dB @0.6-18GHz |
Connector Pin |
Beryllium Copper, Gold Plate |
|
|
Amplitude Balance |
≤±1.5dB |
Solder |
Lead Free, RoHS Compliant |
|
|
Phase Balance |
≤±9° |
Operating Temperature |
-55～+85℃ |
|
|
1Power Handling |
Forward ≤30Watt; Reversed ≤1Watt |
Operating Humidity |
Up to 95%,Non- Condensing |
|
|
Impedance |
50Ω |
Weight |
3500g |
|
|
Port Connectors |
SMA-Female |
|||
1Power Handling guaranteed when load’s VSWR within 1.50:1
