Product Details
| Technical Data Sheet | ||||
| Frequency Range | 350~450MHz | Finish | Painted Blue_ RAL #5007 | |
| Insertion Loss | ≤0.4dB (Excl. Coupling
Loss 1.26dB) |
Connector Body | Brass, Tri-Alloy Plate | |
| Coupling Factor | ≤6±1dB | Housing | Aluminum, 6061 T6
Clear Chem Conversion Film |
|
| Coupling Sensitivity | ≤±0.5dB | Connector Pin | Beryllium Copper, Gold Plate | |
| Directivity | ≥20dB | Solder | Lead Free, RoHS Compliant | |
| VSWR | Primary ≤1.20:1
Secondary ≤1.20:1 |
Operating Temperature | -20～+70℃ | |
| 1Power Handling | Incident ≤50Watt;
Reflected ≤5Watt |
Operating Humidity | Up to 95%,Non- Condensing | |
| Impedance | 50Ω | Weight | 230g | |
| Port Connectors | N-Female | |||
