Product Details
|
Technical Data Sheet |
||||
|
Frequency Range |
0.7~6GHz |
|
Finish |
Natural oxygen |
|
Insertion Loss |
≤0.6dB@0.7-6GHz ≤3.0dB@0.7-26GHz (Excl. Coupling Loss 0.46dB) |
|
Connector Body |
Brass, Tri-Alloy Plate |
|
Coupling Factor |
≤10±0.7dB |
|
Housing |
Aluminum, 6061 T6 Clear Chem Conversion Film |
|
Coupling Sensitivity |
≤±0.7dB |
|
Connector Pin |
Beryllium Copper, Gold Plate |
|
Directivity |
≥15dB |
|
Solder |
Lead Free, RoHS Compliant |
|
VSWR |
≤1.30:1@0.7-6GHz ≤1.60:1@0.7-26GHz |
|
Operating Temperature |
-20～+65℃ |
|
1Power Handling |
Incident ≤50Watt; Reflected ≤50Watt |
|
Operating Humidity |
Up to 95%,Non- Condensing |
|
Impedance |
50Ω |
|
Weight |
70g |
|
Port Connectors |
SMA-Female |
|
|
|
1Power Handling guaranteed when load’s VSWR within 1.50:1.
