Product Details
| Technical Data Sheet | ||||
| Frequency Range | 1~4GHz | Finish | Painted Blue_ RAL #5007 | |
| Insertion Loss | ≤0.3dB (Excl. Coupling
Loss 0.04dB) |
Connector Body | Brass, Nickel Plate | |
| Coupling Factor | ≤30±1.0dB | Housing | Aluminum, 6061 T6
Clear Chem Conversion Film |
|
| Coupling Sensitivity | ≤±1.0dB | Connector Pin | Beryllium Copper, Gold Plate | |
| Directivity | ≥17dB | Solder | Lead Free, RoHS Compliant | |
| VSWR | Primary ≤1.25:1
Secondary ≤1.25:1 |
Operating Temperature | -40～+85℃ | |
| 1Power Handling | Incident ≤400Watt;
Reflected ≤50Watt |
Operating Humidity | Up to 95%,Non- Condensing | |
| Impedance | 50Ω | Weight | 550g | |
| Port Connectors | N-Female | |||
1Power Handling guaranteed when load’s VSWR within 1.50:1.
