Product Details
| Technical Data Sheet | ||||
| Frequency Range | 2~18GHz | Finish | Painted Blue_ RAL #5007 | |
| Insertion Loss | ≤0.7dB (Excl. Coupling
Loss 0.14dB) |
Connector Body | Passivated Stainless Steel | |
| Coupling Factor | ≤15±0.7dB | Housing | Aluminum, 6061 T6
Clear Chem Conversion Film |
|
| Coupling Sensitivity | ≤±0.7dB | Connector Pin | Beryllium Copper, Gold Plate | |
| Directivity | ≥15dB | Solder | Lead Free, RoHS Compliant | |
| VSWR | Primary ≤1.40:1
Secondary ≤1.40:1 |
Operating Temperature | -55～+85℃ | |
| 1Power Handling | Incident ≤50Watt;
Reflected ≤2Watt |
Operating Humidity | Up to 95%,Non- Condensing | |
| Impedance | 50Ω | Weight | 30g | |
| Port Connectors | SMA-Female | |||
1Power Handling guaranteed when load’s VSWR within 1.50:1.
