Product Details
Features
High Rejection,Low Insertion Loss
High reliability,Compact size
Electrical specifications
|
Parameters |
UPLINK |
DWNLINK |
|
|
Frequency Range |
U7C |
746～757MHz |
776～787MHz |
|
PCS |
1850～1910MHz |
1930～1990MHz |
|
|
Insertion Loss |
U7C≤2.5dB; PCS≤3.0dB |
||
|
Ripple in Band |
≤1.5dB |
≤1.5dB |
|
|
VSWR |
≤1.30:1 |
≤1.30:1 |
|
|
Rejection |
U7C |
≥70dB@776～787MHz |
≥70dB@746～757MHz |
|
PCS |
≥70dB@1930～1990MHz |
≥70dB@1850～1910MHz |
|
|
Power |
CW ≤50Watt; Peak Instantaneous ≤500Watt |
||
|
Ports Impedance |
50Ω |
||
|
Connectors |
Com:N-Female; Others:SMA-Female |
||
|
Surface Color |
Black |
||
|
Wight |
2100g |
||
Environmental Parameters
Operating Temperature -0～+40℃
Operating Humidity Up to 90%,Non- Condensing
