Product Details
| Center Frequency (F0) | 5.5GHz |
| Pass Band Frequency | 5.15～5.85GHz |
| Pass Band Insertion Loss | ≤1.0dB |
| Pass Band VSWR | ≤1.3:1 |
| Stop Band Rejection | ≥60dB @ 4.0GHz
≥60dB @ 7.0GHz |
| Impedance | 50 ohms |
| Power Handling | CW:≤10W ; Peak Instantaneous:≤50W |
| Connectors | SMA-Female |
| Surface Finish | Blue Paint |
