Product Details
|
Center Frequency(F0) |
434MHz |
|
|
Pass Band Frequency |
433 ~ 435MHz |
|
|
Pass Band Insertion Loss |
≤2.5dB |
|
|
Pass Band Return Loss |
≥18dB |
|
|
Stop Band Rejection |
≥70dB @ DC ~ 424MHz |
≥70dB @ 444 ~ 1000MHz |
|
Impedance |
50 Ohms |
|
|
Power Handling |
10W Max. |
|
|
Connectors |
N-Female |
|
|
Surface Finish |
Painted Blue |
|
|
Dimensions |
122*83*62mm |
|
|
Net weight |
TBD |
|
|
Weight |
830g |
|
