Product Details
| Technical Data Sheet | ||||
| Frequency Range | 0.5~1.0GHz | Finish | Painted Blue_ RAL #5007 | |
| Nominal Split | 3.01dB | Connector Body | Passivated Stainless Steel | |
| Insertion Loss | ≤0.3dB | Housing | Aluminum, 6061 T6 Clear Chem Conversion Film | |
| Isolation | ≥22dB | |||
| Amplitude Balance | ≤±0.5dB | Connector Pin | Beryllium Copper, Gold Plate | |
| Phase Balance | ≤±2° | Solder | Lead Free, RoHS Compliant | |
| VSWR | ≤1.15:1 | Operating Temperature | -55～+85℃ | |
| 1Power Handling | Average ≤50Watt Peak ≤1KW | Operating Humidity | Up to 95%,Non- Condensing | |
| Impedance | 50Ω | Weight | 50g | |
| Port Connectors | SMA-Female |
1Power Handling guaranteed when load’s VSWR within 1.50:1
